You can choose it from viewports toolbar (which I prefer) I wish this feature exist at that time! You can select viewport(s) and then change the scale using standard scale in your scale list. I remember when I had to use zoom scale, then typing nX or nXP. Tip #4: Scaling Viewport by Choosing from Scale List The new boundary can be anywhere, doesn’t have to be inside or intersect existing viewport. 19) Which of the following command in AutoCAD is used to create multiple viewports in the layout EATTEDIT VPORTS QSELECT GROUP. 1) -When I go to plot, only the viewport on the right shows up. Everything appears fine in paperspace (see FIG. This isnt an issue on the original dwg that I copied them from.
Autocad viewport pdf#
I don’t think there is a restriction about this tool. The viewports are on their own non-plot layer and the pdf underlays are on a plottable layer. Now, what if you already have viewport and want to convert it to other shape? You can use clip.Īfter activating this tool, choose the viewport then choose the polygon. Create from object can be used for closed objects like circles, polygons, and even ellipse! Tip #3: Clip Viewport Using create polygonal is just the same with using polyline tool, but you have to create a closed polygon. Tip #2: Creating Irregular Viewportsĭo you need to create irregular viewports? I mean not only rectangular, but maybe circles, polygons, etc? You can do it using create polygonal or create from object. Unfortunately, named viewports don’t allow you to set spacing.Ĭlick OK and place them. You can also use named viewports to do this. This will create the viewports with some spacing between them. One option that is useful here is viewport spacing. You will see the same good friend that you can use to configure viewports in model space. But do you know that you can use predefined configurations? Tip #1: Using Viewport Configurationsĭo you need to create multiple viewports at once? You can do it by creating it one-by-one, or create one then copy or array it.
Here are some tips that you may have overlooked. You can view many area of your drawings in model space, and you can arrange your drawings quickly in layout.
